The following illustration shows how to
connect a component with analog jacks, such
as a tape deck, turntable, etc.
Note
If your turntable has a ground (earth) wire, connect
it to the (U) SIGNAL GND terminal.
Connecting components with
analog audio jacks
Super
Audio CD
player, CD
player
Tu rn t ab le
A
MD deck, Tape deck
A Audio cord (not supplied)
A
A
