Rear panel
41
1
1, 2 23
A Audio signal section
DIGITAL INPUT/OUTPUT jacks (page 22, 26,
27, 28, 29)
HDMI IN/OUT
OPTICAL IN
COAXIAL IN
ANALOG INPUT/OUTPUT jacks (page 20, 22,
26, 27, 29, 31)
AUDIO IN/OUT
AUDIO OUT
White (L)
Red (R)
Black
B Video signal section*
The image quality depends on the connecting
jack.
DIGITAL INPUT/OUTPUT jacks
(page 22, 26, 27, 28, 29)
HDMI IN/OUT
COMPONENT VIDEO INPUT/
OUTPUT jacks (page 22, 26, 27)
Y, P
B, PR IN/OUT
COMPOSITE VIDEO INPUT/
OUTPUT jacks (page 22, 27,
29)
VIDEO IN/OUT
C ANTENNA section
FM ANTENNA jack (page 32)
AM ANTENNA terminals (page 32)
High
quality
Green
(Y)
Blue
(P
B)
Red
(P
R)
Yellow
