Settings menu list
Speaker Settings menu
You can adjust each speaker manually.
You can also adjust the speaker levels after the
Auto Calibration is completed.
Note
The speaker settings are only for the current seating
position.
x SP Pattern (Speaker pattern)
Select “SP Pattern” according to the speaker
system which you are using. Select the speaker
pattern before you perform Auto Calibration.
x Manual Setup
You can adjust each speaker manually on the
“Manual Setup” screen. You can also adjust
the speaker levels after the Auto Calibration is
completed.
To adjust the speaker level
You can adjust each speaker’s level (front left/
right, front left/right high, center, surround
left/right, surround back left/right,
subwoofer).
1 Select the speaker on the screen for
which you want to adjust the level, then
press .
2 Select “Lvl”.
3 Set the level of the selected speaker,
then press .
You can adjust the level from –10.0 dB to
+10.0 dB in 0.5 dB intervals.
Note
When one of the sound fields for music is selected,
no sound is output from the subwoofer if all the
speakers are set to “Large”. However, the sound will
be output from the subwoofer if
– the digital input signal contains LFE signals.
– the front or surround speakers are set to “Small”.
– “MULTI ST.”, “PLII MV”, “PLII MS”, “PLIIX
MV”, “PLIIX MS”, “HD-D.C.S.” or “P. AUDIO”
is selected.
To adjust the distance from the
seating position to each
speaker
You can adjust the distance from the seating
position to each speaker (front left/right, front
left/right high, center, surround left/right,
surround back left/right, subwoofer).
1 Select the speaker on the screen for
which you want to adjust the distance
from the seating position, then press
.
2 Select “Dist”.
3 Set the distance of the selected
speaker, then press .
You can adjust the distance from 1 m 0 cm
to 10 m 0 cm (3 ft 3 in to 32 ft 9 in) in
10 cm (1 in) intervals.
Tip
You can adjust the distance in 1 cm interval
when you have performed the Auto Calibration
and saved the measurement result.
Settings menu Description
Auto Cal. Sets the speaker level or
distance and makes the
measurement automatically
(page 34).
Speaker Sets the speaker position
manually (page 64).
Surround Selects the sound field and
adjusts the surround effect
you choose (page 67).
EQ Adjusts the equalizer (bass/
treble sound) (page 67).
Audio Sets various sound items
(page 68).
HDMI Makes settings for sound/
images from equipment
connected to the HDMI jacks
(page 68).
System Makes settings for the
system of the receiver
(page 69).
