3: Connecting a TV
Be sure to make cable connections before connecting the AC power cord (mains lead).
Connect a TV to the HDMI TV OUT jack. You can set this receiver by operating the menu or
the on-screen instructions displayed on the TV screen.
When you connect a TV, you can watch a video and listen to the sound input from the device
connected to the receiver on the TV. You can also listen to the TV sound from the speaker
through the receiver.
About HDMI features
• Sony recommends that you use an HDMI cable made by Sony or another HDMI-authorized
cable. Be sure to use a High Speed HDMI Cable with Ethernet. For video signals that require
a high bandwidth such as 4K/60p 4:4:4, 4:2:2 and 4K/60p 4:2:0 10 bit etc., be sure to use
a Premium High Speed HDMI Cable with Ethernet, which supports bandwidths up to
18 Gbps.
• When you use high bandwidth video formats such as 4K/60p 4:4:4, 4:2:2 and 4K/60p
4:2:0 10 bit, be sure to set the HDMI signal format. For details, see “Setting the HDMI Signal
Format” (page 35).
• We do not recommend using an HDMI-DVI conversion cable. If you connect an HDMI-DVI
conversion cable to a DVI-D device, the sound and/or image may be lost. Connect
separate audio cables or digital connecting cables, then reassign the input jacks if the
sound is not output correctly.
• All HDMI jacks on the receiver support ITU-R BT.2020 wide color spaces, Deep Color (Deep
Colour), and HDR (High Dynamic Range) contents pass-through.
• The HDMI TV OUT jack supports the eARC or ARC function.
• BT.2020 color space is new wider color standard that is defined for ultra-high definition
television systems.
• HDR is an emerging video format that can display a wider range of brightness levels.
• For details on the supported video formats, visit the Help Guide.
Copyright protection regarding HDMI jacks
• All HDMI jacks on the receiver support 4K resolution and HDCP 2.2 (High-bandwidth Digital
Content Protection System Revision 2.2).
HDCP 2.2 is newly enhanced copyright protection technology that is used to protect
content such as 4K movies.
• To watch HDCP 2.2 protected content such as 4K content, connect the HDMI jacks to jacks
that support HDCP 2.2 on the TV and audio-visual device. For details on whether the TV
and audio-visual device are equipped with HDCP 2.2-compatible HDMI jack, refer to the
operating instructions of the connected device.
Audio cable connection
• When connecting an optical digital audio cable, insert the plugs straight until they click
into place.
• Do not bend or tie optical digital audio cables.
Note

Sony STR-DH790 Specifications

General

Receiver type	Surround
Output impedance	6 - 16 Ω
Pre-out channels	2 SW
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	0.9 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
AirPlay	No
Display	-
HDCP version	2.2
Audio decoders	DSD, DTS, DTS 96/24, DTS-ES, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Dual Mono
Volume control	Rotary
Audio Return Channel (ARC)	Yes
Consumer Electronics Control (CEC)	BRAVIA Sync
FM antenna ports quantity	1
Speakers connectivity type	Clamp terminals
Supported radio bands	FM
Preset stations quantity	30
Audio (L/R) in	4
Multichannel audio input type	RCA
Audio (L/R) out	7
Headphone connectivity	6.3 mm
Multichannel audio output type	Terminals
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	297 mm
Width	430 mm
Height	133 mm
Weight	7400 g
