Sony STR-DH790 User Manual

59
GB
Troubleshooting/Specifications
Supported Playable Formats
The digital audio formats that this receiver can decode depend on the digital audio output
jacks of the connected device. This receiver supports the following audio formats.
1)
Audio signals are output in another format if the playback device does not correspond to the actual
format. For details, refer to the operating instructions of the playback device.
2)
Dolby Atmos is decoded as Dolby Digital Plus or Dolby TrueHD if the speaker pattern is set to “2.0”, “2.1”,
“3.0”, “3.1”, “4.0”, “4.1”, “5.0” or “5.1”.
Supported digital audio formats
Digital audio format
Maximum number of
decoded channels
Connection with the
receiver
Dolby Digital (“DD”) 5.1
COAXIAL/OPTICAL, HDMI,
eARC, ARC
Dolby Digital Plus (“DD+”)
1)
7.1 HDMI, eARC, ARC
Dolby TrueHD (“DTHD”)
1)
7.1 HDMI, eARC
Dolby Atmos – Dolby Digital Plus
(“ATMOS”)
1),2)
5.1.2 or 7.1 HDMI, eARC, ARC
Dolby Atmos – Dolby TrueHD (“ATMOS”)
1),2)
5.1.2 or 7.1 HDMI, eARC
DTS (“DTS”) 5.1
COAXIAL/OPTICAL, HDMI,
eARC, ARC
DTS-ES Discrete (“DTSES.DSC”) 6.1
COAXIAL/OPTICAL, HDMI,
eARC, ARC
DTS-ES Matrix (“DTSES.MTX”) 6.1
COAXIAL/OPTICAL, HDMI,
eARC, ARC
DTS 96/24 (“DTS 9624”) 5.1
COAXIAL/OPTICAL, HDMI,
eARC, ARC
DTS-HD High Resolution Audio
(“DTSHD HR”)
1)
7.1 HDMI, eARC
DTS-HD Master Audio (“DTSHD MA”)
1)
7.1 HDMI, eARC
DTS:X (“DTS-X”)
1)
5.1.2 or 7.1 HDMI, eARC
DTS:X Master Audio (“DTS-X MA”)
1)
5.1.2 or 7.1 HDMI, eARC
DTS Express (“DTS EXP”) 7.1 HDMI, eARC
DSD (“DSD”)
1)
5.1 HDMI
Multi Channel Linear PCM (“PCM”)
1)
7.1 HDMI, eARC

Sony STR-DH790 Specifications

General

Receiver type	Surround
Output impedance	6 - 16 Ω
Pre-out channels	2 SW
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	0.9 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
AirPlay	No
Display	-
HDCP version	2.2
Audio decoders	DSD, DTS, DTS 96/24, DTS-ES, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Dual Mono
Volume control	Rotary
Audio Return Channel (ARC)	Yes
Consumer Electronics Control (CEC)	BRAVIA Sync
FM antenna ports quantity	1
Speakers connectivity type	Clamp terminals
Supported radio bands	FM
Preset stations quantity	30
Audio (L/R) in	4
Multichannel audio input type	RCA
Audio (L/R) out	7
Headphone connectivity	6.3 mm
Multichannel audio output type	Terminals
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	297 mm
Width	430 mm
Height	133 mm
Weight	7400 g
