Hookups and Settings
Step 3: Connecting the Video Cords/HDMI Cord
Select one of the following patterns A through D, according to the input jack on your TV monitor,
projector, or AV amplifier (receiver). This will enable you to view pictures.
A Connecting to a video input jack
You will enjoy standard quality images.
B Connecting to an S VIDEO input jack
You will enjoy high quality images.
C Connecting to component video input jacks (Y, PB/CB, PR/CR)
You will enjoy accurate colour reproduction and high quality images.
If your TV accepts 720p/1080i format signals, you must use this connection.
D Connecting to an HDMI input jack*
Use a certified HDMI cord (not supplied) to enjoy high quality digital picture through the HDMI OUT
jack.
* This hard disk recorder is based on version 1.1 of High-Definition Multimedia Interface Specifications.
This hard disk recorder incorporates High-Definition Multimedia Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
z Hints
• The HIGH DEFINITION OUT indicator on the front panel lights up when outputting 720p/1080i video signals from
the HDMI OUT jack or the COMPONENT VIDEO OUT jacks.
• The recorder’s default video output setting is “1080i.” If the connected TV does not display pictures when using
pattern C or D, change “Video Format” to “576p” or “576i” (page 43).
