Sony VPL-FHZ55 Service Manual

2-22 (E)
VPL-FHZ55
Menu Title Item Name Memory Name
Set Memory Sub Micro
Memory
No Memory Status
Memory
Eco Memory Picture Memory
All Channels
Dynamic Standard Presen
Operation Lauguage ENGLISH
Menu Position BOTTOM LEFT
Status ON
IR Receiver FRONT & REAR
ID Mode ALL
Security Lock OFF
Panel Key Lock OFF
Connection
Power
Network Setting
IP Address Setup AUTO(DHCP)
IP Address
Subnet Mask
Default Gateway
Primary DNS
Secondary DNS
Apply
MAC Address
IPv6 Address Setup Display only
Prefix Display only
IPv6 Default Gateway Display only
DNS Address Setup Display only
Primary DNS Display only
Secondary DNS Display only
MAC Address Display only
Input-A Signal Sel. AUTO
Color System AUTO
Light Output Mode Standard
Constant Brightness OFF
With No Input OFF
With Static Signal
Light
Dimming
Light Dimming 10 min.
Standby Mode STANDARD
Quick Reboot OFF
Direct Power On OFF
Installation Edge Blending OFF
Blending Range
Top 0
Bottom 0
Left 0
Right 0
Zone Black Level Adj.
Zone
Zone1 R 0
G0
B0
Zone2 R 0
G0
B0
Zone3 R 0
G0
B0
(Continue to Next page)

Sony VPL-FHZ55 Specifications

General

Native aspect ratio	16:9
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	8000:1
Screen size compatibility	40 - 600 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	30 °
Focus	Manual
Throw ratio	1.4 - 2.3:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	- %
Service life of light source	20000 h
3D	No
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	40 dB
Noise level (economic mode)	35 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, VIE
Placement	Desktop
Product type	Large venue projector
Product color	White
Power source	DC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Cables included	AC
Remote control type	IR

Weight and Dimensions

Depth	487 mm
Width	390 mm
Height	134 mm
Weight	11000 g
