1414
WM-GX400
11
(11)
1-680-521-
DISPLAY BOARD (SIDE A)
S704
AVLS
NORMAL
LIMIT
S703
ISS
3
2
1
S702
ON OFF
SPEAKER
S704
R720
C719
R721
3
2
1
IC702
R711
R709
R703
L702
R705
S705
EXCEPT CND,5E
MONO
ST
S705
FM
MODE
C752
R701
R752
S702
R753
R743
S712
ENTER
S708
FM
S710
OFF
S709
AM
S701
TUNING
ND701
LIQUID CRYSTAL
DISPLAY
CND,5E
LOCAL
DX
2
3 4 5 6 7
8
9 10
A
1
B
C
D
E
4-8. PRINTED WIRING BOARD – DISPLAY SECTION (SIDE A) –
Note:
• X : parts extracted from the component side.
•
a
: Through hole.
• : Pattern from the side which enables seeing.
• Abbreviation
CND : Canadian
5E : Indication of country of origin (DX, LOCAL)
