3
WM-GX400
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
• The equipment can be removed using the following procedure.
2-1. CABINET (FRONT), CABINET (REAR), "LID, CASSETTE ASSY"
Cabinet (Rear)
Cabinet (Front) Main board
Mechanism deck
HRPE301 (REC/PB/ERASE head),
M601 (CAPSTAN/REEL motor), Belt (AR)
Set
Lid, cassette ASSY Display board
Note on installing the
cassette lid assy
When installing the cassette lid ASSY,
insert the one side of the spring (toggle)
and set the other side into the gap on the
cabinet (front) as shown in the figure.
7
3
6 Remove from projection
6 Remove from projection
1 Screws (+B1.7X9)
2 Claws
5 Flexible board (22 core) (CN302)
4 Flexible board (22 core) (CN301)
Lid, cassette ASSY
Cabinet (front)
Cabinet (rear)
Hand strap
Spring (toggle)
