24
WM-GX400
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian
FR : French
EA : Saudi Arabia
CH : Chinese
JEW : Tourist
E : Indication of country of origin
(ST, MONO)
9E : No Indication of country of origin
5E : Indication of country of origin
(DX, LOCAL)
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3021-364-A MAIN BOARD, COMPLETE
(AEP,E,9E,CH,EA,JEW)
* A-3021-367-A MAIN BOARD, COMPLETE (CND,5E)
* A-3021-369-A MAIN BOARD, COMPLETE (FR)
*********************
4-017-441-01 CUSHION (B)
<CAPACITOR>
C2 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(EXCEPT CND,5E)
C2 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(CND,5E)
C3 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C5 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C6 1-115-156-11 CERAMIC CHIP 1uF 10V
C7 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C8 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C9 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C10 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C11 1-115-156-11 CERAMIC CHIP 1uF 10V
C12 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C16 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C17 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C18 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C19 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C20 1-115-156-11 CERAMIC CHIP 1uF 10V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C24 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C25 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C26 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C28 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C29 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C30 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C32 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C34 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C37 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C39 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C40 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C42 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C43 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C44 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C48 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C49 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C50 1-115-156-11 CERAMIC CHIP 1uF 10V
C51 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C53 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-115-156-11 CERAMIC CHIP 1uF 10V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C105 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C151 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C152 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C154 1-115-156-11 CERAMIC CHIP 1uF 10V
C155 1-115-156-11 CERAMIC CHIP 1uF 10V
C156 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C171 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C172 1-115-156-11 CERAMIC CHIP 1uF 10V
C173 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C176 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C177 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C178 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C179 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C180 1-115-156-11 CERAMIC CHIP 1uF 10V
C181 1-115-156-11 CERAMIC CHIP 1uF 10V
C182 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
C184 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C185 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C186 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C187 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C188 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C201 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C204 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C205 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C251 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C252 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C254 1-115-156-11 CERAMIC CHIP 1uF 10V
C255 1-115-156-11 CERAMIC CHIP 1uF 10V
C256 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C271 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C272 1-115-156-11 CERAMIC CHIP 1uF 10V
C273 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C276 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
MAIN
