4
WM-GX400
2-2. MAIN BOARD
2-3. MECHANISM DECK
4
Cabinet (front)
Black
Orange
Red
White
3 Screw (M1.4)
3 Screw (M1.4)
2 Flexible board (9 core)
(CN303)
1 Remove soldering
(four places)
Main board
2
1 Screws (IB LOCK)
Cabinet (front)
Mechanism deck (MT-WMGX400-175
)
