XAV-W1
3-216-785-41 (1)
General Settings
Various settings are configurable from the
following two setup menus.
• DVD setup menu (page 39)
Allows configuration of items related mainly to
DVD playback.
• Setup menu (page 42)
Allows configuration of system-related items.
DVD setup
The DVD setup menu includes the following
categories.
• Language Setting: Sets the menu, subtitle
language, etc. (page 40).
• A/V Setting: Adjusts the sound/monitor
settings (page 40).
• Parental Control: Adjusts the parental
control settings (page 41).
• Play Mode: Adjusts the settings for playback
(page 41).
• Reset DVD SETUP: Resets all setting items
in DVD setup (page 41).
Basic operation of DVD setup
You can set items in the menu by the following
procedure.
E.g., when setting “Monitor Type” to “4:3 Pan
Scan.”
1 While the unit is off/DVD is played,
touch “DVD SETUP.”
The DVD setup menu appears.
2 Touch .
The “A/V Setting” display appears.
3 Touch “Monitor Type.”
The options appear.
4 Touch “4:3 Pan Scan.”
The setting is complete.
To scroll the options (only when required), touch
“Prev v” or “Next V.”
To return to the previous display, touch .
To close the DVD setup menu, touch “DVD
SETUP.”

Sony XAV-W1 Specifications

Power

power consumption (in operation)	45 W
output power	52 W x 4
current drain	3 - 8 amps

Audio Specifications

output impedance	4-8 Ohms
sensitivity (FM usable)	9 dBf
signal-to-noise ratio (DVD/CD player)	120 dB

Display

display size	7 inches
aspect ratio	16:9
display technology	TFT Active Matrix LCD

Weight and Dimensions

weight	2.4 kg
dimensions	178 x 100 x 189 mm
tilt range	45°
