Sony Xperia Z1 User Manual

11 Main camera lens
12 Camera light
13 Second microphone
14 NFC™ detection area
15 Memory card slot cover
16 Charger/USB cable port cover
17 Charging dock connector
Do not insert fingers or other objects into the opening for the second microphone (illustrated in
item 13 above) to avoid damaging your device.
Assembly
A protective plastic sheet is attached to the screen. You should peel off this sheet
before using the touchscreen. Otherwise, the touchscreen might not function
properly.
To insert the micro SIM card
Do not insert a memory card into the micro SIM card slot.
8
This is an Internet version of this publication. © Print only for private use.

Sony Xperia Z1 Specifications

General

RAM	2 GB
Front Camera	2 MP
Battery	Non-removable Li-Ion 3000 mAh
Operating System	Android 4.2 (Jelly Bean), upgradable to 5.1 (Lollipop)
Weight	170 g (6.00 oz)
SIM	Micro-SIM
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.0, A2DP, aptX
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Sensors	Accelerometer, gyro, proximity, compass, barometer
Display	5.0 inches, 1080 x 1920 pixels
Processor	Qualcomm MSM8974 Snapdragon 800
Storage	16 GB
Main Camera	20.7 MP
Dimensions	144 x 74 x 8.5 mm
Water Resistance	IP58 dust proof and water resistant over 1.5 meter and 30 minutes
Radio	Stereo FM radio with RDS
USB	microUSB 2.0 (MHL TV-out)
