Sony XVS-7000 User Manual

44
b Region selection buttons
These buttons select the target region to control.
You can select more than one region. The first selected
button becomes the reference region, and is lit green.
Subsequent selected buttons are lit amber.
With the exception of the [MASTR] and [ALL] buttons,
you can assign arbitrary regions to the region selection
buttons in the Setup menu. Up to four regions can be
assigned to a button.
When a button with more than one region assigned is
selected, the reference region is set according to the
priority. You can temporarily change the region selection
and reference region in the Key Frame >Region Select
menu (6117).
For details, see “Assigning a Region to the Region
Selection Buttons in the Numeric Keypad Control Block”
(page 410) and “Recalling regions to edit (menu)”
(page 308).
c Function selection buttons
These buttons are used for recalling and saving shotboxes,
snapshots, keyframe effects, macros, and for other tasks.
a) If more than one region is assigned to a region selection button and there
is a region not selected in the Key Frame >Region Select menu (6117), the
[RCALL] button or [STORE] button flashes amber (excluding in macro
operation mode).
d Display
The following information is displayed.
• Left-side display (rows 1 to 3), right-side display (rows
1 to 2): Name of currently selected region (reference
region is highlighted in reverse video)
• Right-side display (rows 3 to 4): Register number, input
numeric values, and so on
e Numeric keypad buttons
These buttons are used for entering numeric values and
adding snapshot attributes.
SNAPSHOT • Switches to snapshot operation
mode.
• Recalls and saves snapshots.
SHOTBOX • Switches to shotbox operation
mode.
• Recalls and saves shotboxes.
MCRO (macro) • Switches to macro operation
mode.
• Recalls, saves, and edits macros.
Button name Description
M/E1 to M/E5, P/P Selects the M/E-1 to M/E-5 and
PGM/PST regions.
USER 1 to USER 8 Selects the USER1 to USER8
regions.
DME1 to DME4 Selects the DME1 to DME4
regions.
DEV1 to DEV12 (Assignment of the [DEV4] to
[DEV12] buttons in the Setup menu
is required.)
Selects the device 1 to device 12
regions.
P-BUS Selects the P-Bus region.
GPI Selects the GPI region.
RTR (Assignment in the Setup menu is
required.)
Selects the router region.
MCRO (Assignment in the Setup menu is
required.)
Selects the macro region.
MASTR Selects the master region.
Button name Description
ALL • Selects all specified regions if
there is no region selected.
• Deselects all region selections if
there is a region selected.
Button name Description
UNDO After recalling a register, returns to
the state before the register was
recalled.
STORE STATS (store
status)
• Saves data in the register, and
the button is lit amber.
• When the [STORE STATS] button
is lit amber, you can press and
hold the [STORE STATS] button
and press the [UNDO] button to
return to the state before data
was saved.
TC (timecode) Switches the numeric keypad to
timecode input mode.
STORE
a)
• Switches the mode for saving a
shotbox, snapshot, keyframe
effect, master snapshot, master
timeline, or macro in a register
(store mode).
• During store mode, the [STORE]
button is lit amber.
RCALL (recall)
a)
• Switches the mode for recalling a
shotbox, snapshot, keyframe
effect, master snapshot, master
timeline, or macro stored in a
register (recall mode).
• During recall mode, the [RCALL]
button is lit amber.
Button name Description
0 to 9 Enters numeric values.
Button name Description
