– 8 –
ENGLISH
3. Connecting Cables and AC Adapter
3-1. Interface Cable
Note that the interface cable is not provided. Please use a cable that meets
specifications.
CAUTION
Before connecting/disconnecting the interface cable, make sure that
power to the printer and all the devices connected to the printer is turned
off. Also make sure the power cable plug is disconnected from the AC
outlet.
3-1-1. Serial Interface (RS-232C) Cable
(1) Make sure the printer is turn off.
(2) Connect the interface cable to the connector on the rear panel of the printer.
(3) Tighten the connector screws.
Serial interface cable
To Next Page
