Star Micronics TSP800 Series User Manual

– 1 –
ENGLISH
1. Parts Identification and Nomenclature
Standard Model
Roll paper
User’s manual
Cover open lever
Pull this lever in the
direction of the arrow to
open the printer cover.
Control panel
Features LED indica-
tors to indicate printer
status and switches to
operate the printer.
Printer cover
Open this cover to load or
replace paper.
Power switch
Used to turn on/off
power to the printer.
Power connector
For connection of the AC adapter.
Never unplug the AC adapter
while the printer is on.
Peripheral drive connector
Connects to peripheral
units such as cash
drawers, etc.
Do not connect this to a
telephone.
Interface connector
For connection to a
host computer.
Ferrite core Fastener
(A model with an
RS-232C interface
is not available.)
(Included with
Parallel and
Ethernet model)
(For USB interface)
(For parallel and
Ethernet interfaces)
