– 107 –
APPENDIX
A-5. Environmental Requirements
(1) Operating
Temperature 5°C to 45°C
Humidity 10% to 90% RH (without condensation)
(2) Transport/storage (except for paper)
Temperature -20°C to 60°C
Humidity 10% to 90% RH (without condensation)
A-6. Reliability
(1)MCBF 37 million lines (based on an average printing rate of
12.5% with paper thickness in the range 65 µm to 75 µm)
20 million lines (based on an average printing rate
of 12.5% with paper thickness in the range 76 µm
to 150 µm)
(2) Cutter life 1.0 million cuttings (if the paper thickness is between
65 and 75 µm)
0.9 million cuttings (if the paper thickness is between
75 and 100 µm)
0.18 million cuttings (if the paper thickness is be-
tween 100 and 130 µm)
0.15 million cuttings (if the paper thickness is be-
tween 130 and 150 µm)
(%RH)
34°C90% RH
40°C65% RH
45°C50% RH
90
80
60
40
20
10
01020
Temperature (°C)
Operating environment
range
Relative humidity
Operating temperature and humidity range
30 40 50
