– 14 –
1 80701770 WIRE 18UL1007BRN145TT 1 TUP992 S
2 37497000 NEAR-END DETECTOR UNIT TUP9 1 O
3 37490050 BOARD CHASSIS U UNIT TUP9 1 S
4 NPN BOARD CHASSIS UNIT TUP9 1
5 NPN FRAME L UNIT TUP9 1
6 NPN FRAME R UNIT TUP9 1
7 37490000 MECHANISM BASE UNIT TUP9 1 TUP992 S
37490060 MECHANISM BASE A UNIT TUP9 1 TUP942 S
8 32045600 PAPER GUIDE TUP9 1 S
9 NPN BOTTOM FRAME TUP9 1
10 NPN FRAME STAY TUP9 1
11 30510530 SPRING E100-100-0284 2 S
12 04991204 FASTENER T18S 4 TUP992 S
12 04991204 FASTENER T18S 3 TUP942 S
13 01923004 DESIGNED SCREW 3-4 3 S
14 01903101 SCREW TAT 3-6 CT-FL 11 TUP992 S
01903101 SCREW TAT 3-6 CT-FL 9 TUP942 S
15 01903030 SCREW TR 3-4 FL 4 S
16 01914003 SCREW TR 4-10 WS/WF 2 S
17 33910660 ROLL PAPER HOLDER 1 TUP9 2 S
18 31380100 ROLL PAPER SHAFT TUP9 1 S
19 33910670 ROLL PAPER HOLDER 2 TUP9 2 S
20 33910680 ROLL PAPER HOLDER 3 TUP9 2 S
21 31382040 SHAFT C TMP7 1 TUP992 S
22 30781440 ADAPTER SET PS60L-24A US 1 OPTION O
30781450 ADAPTER SET PS60L-24A EU 1 OPTION O
30781460 ADAPTER SET PS60L-24A UK 1 OPTION O
30781470 ADAPTER SET PS60L-24A AS 1 OPTION O
30781480 ADAPTER SET PS60L-24A CH 1 OPTION O
23 39607400 INTERFACE BOARD IFBD-HD04 1 SERIAL IF (25 PIN) O
39607430 INTERFACE BOARD IFBD-HN04 1 SERIAL IF (9 PIN) O
39607421 INTERFACE BOARD IFBD-HU04 1 SERIAL IF (USB) O
39607440 INTERFACE BOARD IFBD-HE04 1 ETHERNET O
39607411 INTERFACE BOARD IFBD-HC04 1 PARALLEL IF O
- 39590020 RHU-T900 1 OPTION O
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
1-2. Parts List
Printer Assembly
To Next Page
