Star Micronics TUP900 Series User Manual

– 18 –
3. Sub-Assembly
3-1. Frame R Unit
9-1 NPN FRAME R ASSY TUP9 1
9-2 33210520 BUSHING TUP9 1 S
9-3 30211050 PF ROLLER BEARING TMP6 1 S
9-4 04991254 CORD CLAMP EDS-1208U 1 S
9-5 04020016 STOP RING SE4.0 1 S
9-6 02010401 HEXAGON NUT NH4-1 2 S
9-7 01914003 SCREW TR 4-10 WS/WF 2 S
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
3
5
7
2
1
6
4
9 -
