– 46 –
C1 NPN CHEM. CAPA. 1UF 50V 1
C2 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
C3-6 NPN CERA.CAPA.CHIP1608 0.1UF 25V 4
C26-35 NOT MOUNTED
R1-2 NPN CHIP RESISTOR 10 K-OHM 1/16W 2
R4-5 NPN CHIP RESISTOR 10 K-OHM 1/16W 2
R6-7 NOT MOUNTED
R8 NPN CHIP RESISTOR 0 OHM 1/16W 1
R11-13 NPN CHIP RESISTOR 10 K-OHM 1/16W 3
RA1 NPN RESIS. ARRAY 10 K-OHM 1/8W 8EL 1
IC1 08200203 IC-I/F SP208ECA/TR* 1 S
IC2-3 NOT MOUNTED
IC4 NPN CMOS TC7WU04FU*12L 1
L1-7 NPN CHIP BEADS IND. BK1608HS601* 7
L8-9 NOT MOUNTED
DSW1 NPN DIP SWITCH 210B008MS 1
CN1 NPN CONNECTOR PHEC40P-R111 1
CN2 NPN CONNECTOR 17LE-23090-27D41 1
CN3 NOT MOUNTED
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
9-2. Parts List
Serial Interface Board (9pin)
To Next Page
