Star Micronics TUP900 Series User Manual

– 29 –
2-4-1 37487330 PE DETECTOR ASSY TMP9 1 S
2-4-2 NPN UPPER GUIDE TMP9 1
2-4-3 NPN PAPER GUIDE BASE TMP9 1
2-4-4 33910440 SIDE GUIDE L TMP9 1 S
2-4-5 33910430 SIDE GUIDE R TMP9 1 S
2-4-6 NPN GUIDE PINION 18X0.5 TMP9 1
2-4-7 NPN RACK TMP9 2
2-4-8 04300782 O-RING 7.8X1.9 P8SILICON50 1 S
2-4-9 01902024 SCREW TAT 2-6 2 S
2-4-10 01902028 SCREW TAT 2-4 1 S
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
3-10.Paper Guide Unit (TMP942)
3
8
10
1
2
9
4
6
5
7
7
9
2 - 4 -
