Star Micronics TUP900 Series User Manual

– 36 –
BC01 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
BC02A-2B NPN CERA.CAPA.CHIP1608 0.01UF 50V 2
BC02C-2D NPN CERA.CAPA.CHIP1608 0.022UF 50V 2
BC03A NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
BC03B-3D NPN CERA.CAPA.CHIP1608 0.022UF 50V 3
BC03E NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
BC03F-3G NPN CERA.CAPA.CHIP1608 0.022UF 50V 2
BC04 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
BC11 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
BC12-13 NPN CERA.CAPA.CHIP1608 0.1UF 25V 2
BC14 NPN CERA. CAPA. CHIP 0.1UF 50V 1
BC21A NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
BC21B NPN CHEM. CAPA. 47UF 35V 1
BC22 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
BC23 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
BC24 NPN CHEM. CAPA. 47UF 35V 1
BC25 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
BC31 NPN CHEM. CAPA. 47UF 35V 1
BC32 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
C01 NPN CERA.CAPA.CHIP1608 1000PF 50V 1
C02 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C03-04 NPN CERA.CAPA.CHIP1608 0.022UF 50V 2
C09 NPN CERA. CAPA. CHIP 1UF 10V 1
C12 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
C13 NPN CHEM. CAPA. 1000UF 35V 1
C14 NPN CHEM. CAPA. 100UF 50V 1
C15 NPN CHEM. CAPA. 470UF 10V 1
C16 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
C17 NPN CERA. CAPA. CHIP 1UF 10V 1
C18 NPN CHEM. CAPA. 220UF 10V 1
C20 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C21 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
C22 NPN CHEM. CAPA. 47UF 35V 1
C23 NPN CERA.CAPA.CHIP1608 3900PF 50V 1
C24 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
C26 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C28 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C30 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C301 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C32 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
C34 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
C36 NPN CERA.CAPA.CHIP1608 0.01UF 50V 1
C37 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
C39 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
C40 NPN CERA. CAPA. CHIP 100PF 50V 1
C400-404 NPN CERA.CAPA.CHIP1608 470PF 50V 5
C405-408 NPN CERA.CAPA.CHIP1608 0.01UF 50V 4
C41-42 NPN CERA.CAPA.CHIP1608 0.01UF 50V 2
C43-44 NPN CERA.CAPA.CHIP1608 1000PF 50V 2
C45-46 NPN CERA.CAPA.CHIP1608 0.022UF 50V 2
C47 NPN CERA. CAPA. CHIP 100PF 50V 1
C48-49 NPN CERA.CAPA.CHIP1608 1000PF 50V 2
CN11 NPN CONNECTOR 5273-04A 1
CN21 NPN CONNECTOR B15B-PH-K-S 1
CN22 NPN CONNECTOR B16B-PH-K-S 1
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
5-2. Parts List
Main Logic Board
