BC1 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
BC2A-2C NPN CERA.CAPA.CHIP1608 0.022UF 50V 3
BC3 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
BC4-5 NPN CERA.CAPA.CHIP1608 0.022UF 50V 2
C01 NPN CERA.CAPA.CHIP1608 0.22UF 10V 1
C02 NPN CERA.CAPA.CHIP1608 0.022UF 50V 1
C03 NPN CHEM. CAPA. CHIP 4.7UF 35V 1
C04 NPN TANTALUM CAPA. CHIP 2.2UF 16V 1
C05 NPN CERA.CAPA.CHIP1608 0.1UF 25V 1
C06 NPN CERA.CAPA.CHIP1608 33PF 50V 1
C07 NPN CERA.CAPA.CHIP1608 680PF 50V 1
C08 NPN CERA.CAPA.CHIP1608 0.1UF 16V 1
C09-10 NOT MOUNTED
C11 NPN CERA. CAPA. CHIP 51PF 50V 1
CN1 NPN CONNECTOR PHEC40P-R111 1
CN2 NPN CONNECTOR V23590-T3111 1
IC1 NPN IC-RESET M51953BFP*E2 1
IC2 NPN CPU M37641M8-128FP 1
IC3 NPN IC SOCKET IC160-0324-300 1
NPN OTPROM A276308AL-70 1
IC4 NPN CMOS 74LV02AFP*EL 1
IC5 NPN CMOS 74LV573AFP*EL 1
IC6 NPN CMOS 74LV1G04ACME* 1
L1-10 NPN CHIP RESISTOR 0 OHM 1/10W 10
RA01-02 NPN RESIS. ARRAY CHIP MNR14J101* 2
RA03-04 NOT MOUNTED
RA05 NPN RESIS. ARRAY CHIP MNR14J101* 1
R01 NPN CHIP RES1608 1.5 KOHM 1/16W 5% 1
R02-09 NPN CHIP RESISTOR 100 OHM 1/16W 8
R10-11 NOT MOUNTED
R12 NPN CHIP RESISTOR 10 K-OHM 1/16W 1
R13 NOT MOUNTED
R14 NPN CHIP RES1608 1.5 KOHM 1/16W 5% 1
R15-16 NPN CHIP RES3216 33 OHM 1/8W 1% 2
R17 NPN CHIP RESISTOR 1 K-OHM 1/16W 1
R18-19 NPN CHIP RESISTOR 10 K-OHM 1/16W 2
R20 NPN CHIP RESISTOR 330 OHM 1/16W 1
R21 NPN CHIP RESISTOR 100 OHM 1/16W 1
R22-26 NPN CHIP RESISTOR 10 K-OHM 1/16W 5
R27 NPN CHIP RESISTOR 470 OHM 1/16W 1
TR1 NPN DIGITAL TRANSISTOR FN1A4P 1
TR2 NPN DIGITAL TRANSISTOR FA1A4P 1
ZD1 NPN ZENER DIODE CHIP NNCD5.6LG*T1 1
XTAL NPN CERA. OSC CHIP EFJC2405E5B* 1
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
10-2.Parts List
USB Interface Board
