MAINTENANCE MANUAL
STEMME TSA-M
MAINTENANCE MANUAL
STEMME TSA-M
06-20-00
Page 01
AIRCRAFT ZONING
1. General
A. The S6 is divided into numbered zones to provide a method for locating components or parts
throughout the aircraft.
This Aircraft zoning corresponds to the usual standard.
B. The zones are identified by a (3) three-digit number. The first digit in the sequence denotes the
major zone:
Major Zones: (1) 100 - Front of aircraft to rear wall of cockpit
(2) 200 - Rear wall of cockpit to attachment of tail boom and frame
(3) 300 - Attachment of tail boom and frame to end of aircraft
(4) 500 - Left wing
(5) 600 - Right Wing
(6) 700 - Landing Gear
The second digit in the sequence further divides the zones into sub-zones (Zone 110 - Propeller
and Spinner, Zone 120 - upper and lower cowling). The third digit (if needed) divides the sub-
zone into further subdivisions.
Example:
124
Major Zone Further Sub-Zone
Sub-Zone
2. Description
A. For a breakdown of the aircraft zones, refer to Figure 1.
Nov 18/11
