Original assembly/operating instructions Gear limit switch Type series 51 • No. 151-00004 H • 01.2018 16
Gear size
Nominal revolutions at 15° - cam disc
Gear reduction i
1 drive shaft rev. = cam disc angle of
rotation in degrees
Mechanical hysteresis °
Max. input speed [rpm]
Min. input speed [rpm] (only when
used as a changeover)
67 70,000 5,14 0,11 − 0,22 1800 10,9
110 115,714 3,11 0,19 − 0,4 1800 18
180 188,929 1,9 0,31 − 0,6 1800 29,4
280 300,000 1,2 0,5 − 1,0 1800 46,7
470 495,918 0,73 0,84 − 1,7 1800 77,1
770 809,694 0,44 1,35 − 2,6 1800 125
1200 1285,714 0,28 2,1 − 4,1 1800 199
2000 2125,364 0,17 3,5 − 10,3 1800 330
3300 3470,117 0,1 5,5 − 11,3 1800 539
5200 5510,204 0,06 9,1 − 17,8 1800 856
8700 9108,705 0,04 15,1 − 29,5 1800 1415
14200 14871,928 0,02 24,7 − 48,2 1800 -
1
2
3
4
4.1.3 Gear data, type series 51 DZ
One revolution of the adjustment worm corresponds to 3,168° on the cam disc.
