FORESTER NA. (E)
6
Interior equipment
6-17
– CONTINUED –
J To install the cover
1. Insert the both ends of the cover housing into the retainers.
2. Attach the fastening straps to the pillows.
The cover can be installed in either of two positions.
Cargo anchorage eyelets
CAUTION
The cargo anchorage eyelets are designed only for securing light
luggage. Never try to secure any luggage which weighs more
than the load capacity of the anchorage eyelets. The maximum
load capacity is about 44 lb. (20 kg) per eyelet.
HS0115
The luggage compartment is equipped with four anchorage eyelets so
that luggage can be secured with a luggage net or ropes.
When using the anchorage eyelets, raise them up. When not in use,
lower the eyelets down.
To Next Page
