FORESTER NA. (E)
10-36
Brake pedal
Check the brake pedal free play and reserve distance according to the
maintenance schedule in the warranty and maintenance booklet.
J Checking the brake pedal free play
OM-H0224
0.04 — 0.12 in
(1.0 — 3.0 mm)
Stop the engine and firmly depress the brake pedal several times. Light-
ly press the brake pedal down by finger to check the free play with a
force of less than 10 N (2 lb, 1 kg).
If the free play is not within proper specification, contact your SUBARU
dealer.
J Checking the brake pedal reserve distance
OM-H0225
More than
2.56 in
(65 mm)
