7
+
/
/
/
DC EMI
FILTER
AC EMI
FILTER
3-phase full bridge(IGBT)
L Filter
Output Transformer
AC Main Contactor
AC Auxiliay Contactor
AC Main Breaker
PE
1
Figure 2-2 Simple circuit diagram of SG100K3
