Sungrow SG100K3 User Manual

18
4
4.
Electrical Connection
Chapter 4 describes the step-by-step electrical connection process needed to
complete the installation the SG100K3.
Note :: All wiring methods and processes should be in accordance with
Local Electrical Code.
4.1.
W i re Specifications
The DC input wires (including DC positive and DC negative) must be chosen
according to the recommended rating below.
Table 4-1 DC wires recommended sizes
Type
Requirements ( mm
2
)
Requirements ( AWG )
DC + wire
2 input wires with each 70 mm
2
1/0
DC- wire
2 input wires with each 70 mm
2
1/0
M8 Bolt (DC + and DC-)
The AC output wires (including L 1 , L 2 , and L3) must be chosen according to the
recommended sizes below.
Tab l e 4 - 2
AC wires recommended sizes
Type
Requirements ( mm
2
)
Requirements ( AWG )
Grid phase L 1 wire
70 to 85
2/0 to 3/0
Grid phase L 2 wire
70 to 85
2/0 to 3/0
Grid phase L 3 wire
70 to 85
2/0 to 3/0
Grid phase N wire
70 to 85
2/0 to 3/0
M8 Bolt (L 1 , L 2, L 3 )
The ground wires must be chosen according to the recommended sizes below.
Table 4-3 Ground wires recommended sizes
Type
Requirements ( mm
2
)
Requirements ( AWG )
Ground wire
70 to 85
2/0 to 3/0
M8 Bolt
The communication wires must be chosen according to the recommended sizes
below.
Table 4-4 Communication wires recommended sizes
Type
Requirements ( mm
2
)
Requirements ( AWG )
Communication wire
0.75
18
Based on the above tables, users should use proper wires for different terminals with
different specifications.
