Sungrow SG100K3 User Manual

30
6
6.
Appendix A: Technical Data
The following tables list the technical data of the SG100K3. Basic production
information and performance of the SG100K3 are available from these tables.
6.1.
DC Parameters
Max. DC Power
110kWp
MPPT DC Voltage Range
450V to 820V
Max. DC Voltage
880 V
Max. DC Current
250A
6.2.
AC Parameters
Nominal AC Output Power
100KW
Grid Voltage
400V (310V~450V)
Operating Grid Frequency
50 Hz(47-51.5Hz)
Nominal AC Current
145A
Power Factor
>0.99 at nominal power
THD of grid Current
< 3% at nominal power
Over Voltage Category
Ċ
6.3.
Efficiency
Peak Efficiency
97.0%
European Efficiency
96.4%
