10
figure 2-3 Dimensions of the Inverter
Inverter Model W (mm) H (mm) D (mm)
SG8.0RS-L, SG9.0RS-L, SG10RS-L
521 365 170.5
2.3 Symbols on Product
Symbol Explanation
Parameters on the DC side.
Parameters on the AC on-grid side.
Regulatory compliance mark.
TÜV mark of conformity.
CE mark of conformity.
EU/EEA Importer.
UKCA mark of conformity.
Do not dispose of the inverter together with household waste.
The inverter does not have a transformer.
Disconnect the inverter from all the external power sources be-
fore maintenance!
Read the user manual before maintenance!
2 Product Description User Manual
