63
table 7-2 Description of Run Information
Item
Description
Inverter
Information
Shows basic information such as running state, on-grid running time,
negative voltage to grid, bus voltage, internal air temperature, inver-
ter efficiency, etc.
Input
Shows total DC power, voltage and current of MPPT1 ,MPPT2 and
MPPT3.
Output
Shows daily/monthly/annual/total yield, total active/reactive/appa-
rent power, total power factor, grid frequency, phase voltage and
current.
Grid Information
Shows total export active power, total feed-in energy, total pur-
chased energy.
Load Information
Shows total load active power.
Meter Information
Shows active power and phase active power of the meter.
7.9 Records
Tap Records on the navigation bar to enter the screen showing event records, as shown in
the following figure.
figure 7-6 Records
Chart
Tap Chart to enter the screen showing daily power generation, as shown in the following
figure.
User Manual 7 iSolarCloud App
