5.7 WiFi-P2 Connection
The WiFi-P2 module supports WLAN communication.
5.7.1 WLAN Communication
step 1 Remove the waterproof lid from the COM1 terminal.
step 2 Install the module. Slightly shake it by hand to determine whether it is installed firmly, as
shown below.
step 3 Refer to the guide delivered with the module for the set-up.
- - End
