23
OT terminal crimp-
ing tool (4 mm
2
–6
mm
2
)
MC4 terminal
crimping tool (0.5
mm
2
–1.0 mm
2
)
Electric screwdriver
(M4, M5, M6)
Slotted screwdriver
(M2)
Phillips screwdriver
(M4)
Vacuum cleaner Measuring tape Heat shrink tubing
Heat gun Open-end wrench
(33 mm, 35 mm)
Connector wrench Multimeter (≥ 600
Vdc)
Rubber mallet Hammer drill (φ10) Allen wrench (T27)
4.4 Moving the Inverter
Before installation, remove the inverter from the packing case and move it to the installation
site. Follow the instructions below as you move the inverter:
• Always be aware of the weight of the inverter.
• Lift the inverter using the handles positioned on both sides of the inverter.
• Move the inverter by one or two people or by using a proper transport tool.
• Do not release the equipment unless it has been firmly secured.
User Manual 4 Mechanical Mounting
