Supermicro H11SSL-I User Manual

15
Chapter 1: Introduction
Note: The table above is continued on the next page.
Features
CPU
• Single EPYC 7001/7002* Series Processors (*AMD EPYC 7002 series drop-in support requires board revision 2.x), in
one SP3 socket
Memory
• 1TB Registered ECC DDR4 2666MHz SDRAM in 8 DIMMs
• 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs (Board revision 2.x required)
DIMM Size
• Up to 128GB size at 1.2V
Chipset
• System on Chip
Expansion Slots
• 3 x PCI-E 3.0 x16 slots
• 3 x PCI-E 3.0 x8 slots
• 1 x PCI-E 3.0 x4 M.2 port
• M.2 Interface: 1 PCI-E 3.0 x4
• M.2 Form Factor: 2280, 22110
• M.2 Key: M-Key
Network
• ATEN IPMI from ASPEED AST 2500 BMC for gigabit RJ45 port
• Dual RJ45 LAN ports (Intel i210)
Graphics
• ASPEED AST2500 BMC chip with one (1) VGA port
I/O Devices
• One (1) COM connector
• Eight (8) SATA 3.0 ports or 2x NVMe dual use interface (Mini-SAS HD)
• Eight (8) standard SATA 3.0 ports
• Two (2) SATA DOM
Peripheral Devices
• Two (2) USB 3.0 ports on the rear I/O panel (USB 4/5)
• Two (2) USB 2.0 ports on the rear I/O panel (USB 0/1)
• One (1) USB 3.0 internal "Type A" connection (USB 8)
• One USB 3.0 header (USB 6/7)
• One USB 2.0 header (USB 2/3)
Motherboard Features

Supermicro H11SSL-I Specifications

General

ECC	Yes
Memory voltage	1.2 V
Memory channels	Octa-channel
Memory slots type	-
Supported memory types	DDR4-SDRAM
Maximum internal memory	1024 GB
Supported memory clock speeds	2666 MHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	8
PCI Express x8 (Gen 3.x) slots	3
Supported DIMM module capacities	8GB, 16GB, 32GB, 64GB, 128MB
BIOS type	AMI
ACPI version	5.1
BIOS memory size	128 Mbit
Wi-Fi	No
LAN controller	Intel I210, Realtek RTL8211E
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Super Doctor 5 Watch Dog NMI SUM IPMI 2.0, KVM w/ dedicated LAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Component for	Server
Motherboard form factor	ATX
Number of SATA III connectors	12
Trusted Platform Module (TPM) version	1.2
Processor socket	Socket SP3
Processor manufacturer	AMD
Compatible processor series	AMD EPYC
Supported storage drive interfaces	SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
