6-18
INSPECTION AND MAINTENANCE
52SS0-01E
Coolant Replacement
Since special procedures are required, ask
a SUZUKI dealer or a qualified workshop
for this job.
Air Cleaner
If the air cleaner is clogged with dust, there
will be greater intake resistance, resulting
in decreased power output and increased
fuel consumption.
52SS60090
1) Loosen the air cleaner lower case bolts
(1).
2) Remove the air cleaner lower case.
3) Remove the element from the air
cleaner lower case. If it appears to be
dirty, clean or replace it with a new one.
4) Tighten the air cleaner lower case bolts
to the specified torque.
Tightening torque for air cleaner
lower case bolt:
5 Nm (0.5 kg-m, 4.0 lb-ft)
NOTICE
When putting the cap on the reser-
voir tank, line up the mark on the cap
and the mark on the tank. Failure to
follow this can result in coolant leak-
age.
