5-38
OTHER CONTROLS AND EQUIPMENT
52SS0-01E
Engine Compartment
52SS5023E
To open the engine compartment:
1) Raise the driver’s seat belt buckle (1) to
the seatback position. Store the pas-
senger’s seat belt buckle (2) as shown
in the illustration.
2) For the driver’s seat, slide the seat to
the most rearward position.
Left hand drive vehicle
52SS5015E
WARNING
• Fuel is extremely flammable. Do
not smoke when refueling, and
make sure there are no open
flames or sparks in the area.
• If you need to replace the fuel cap,
use a genuine SUZUKI cap. Use of
an improper cap can result in a
malfunction of the fuel system or
emission control system. It may
also result in fuel leakage in the
event of an accident.
CAUTION
When you slide the driver’s seat rear-
ward, push the seatback.
If you hold the seatback top, your
hand could be pinched between the
seatback and wall, which may result
in personal injury.
To Next Page
