6-32
INSPECTION AND MAINTENANCE
52SS0-01E
52SS6018E
(1) Relay box No.1
(2) Relay box no.2 (vehicles with auto-
matic light operation)
1
11 12 13 14 15
23456789
10
16 17 18 19 20 21 22 23
26
24
2525
(1) (2)
MAIN FUSE / PRIMARY FUSE
(1)
40 A
Battery
(2) – Blank
(3)
40 A
Radiator
(4)
15 A
Horn
(5) 10 A Compressor
(6) 30 A ABS SOL
(7) 25 A Back up
(8) 30 A Starting motor
(9) 30 A Ignition switch2
(10) 40 A Ignition switch
(11) – Blank
(12) 15 A Fuel Injection
(13) – Blank
(14) 10 A Stop light
(15) – Blank
(16) 60 A Power Steering
(17) – Blank
(18) 15 A Headlight (Left)
(19) 25 A Headlight HI
(20) 15 A Headlight (Right)
(21) – Blank
(22) 30 A Blower motor
(23) 40 A ABS motor
(24) 15 A Headlight HI (Right)
(25) 15 A Headlight HI (Left)
(26) – Blank
To Next Page
