General| Displacement | 487 cc |
|---|---|
| Bore x Stroke | 74.0 mm x 56.6 mm |
| Compression Ratio | 9.0:1 |
| Ignition | Electronic ignition (transistorized) |
| Transmission | 6-speed constant mesh |
| Final Drive | Chain |
| Front Suspension | Telescopic, coil spring, oil damped |
| Rear Suspension | Swingarm, coil spring, oil damped |
| Rear Brakes | Drum |
| Front Tire | 110/70-17 |
| Rear Tire | 130/70-17 |
| Engine Type | Air-cooled, 4-stroke, DOHC, parallel twin |
| Fuel System | Carburetor |
| Front Brakes | Disc brake |
| Fuel Capacity | 17 liters |
| Seat Height | 790 mm |
| Max Torque | 40 Nm (29.5 lb-ft) @ 7, 500 rpm |
| Length | 2080 mm |
| Wheelbase | 1405 mm |
