20-14 GS500K4/FK4 (’04-MODEL)
CHASSIS
ITEM N·m kgf-m lb-ft
Steering stem head nut 45 4.5 32.5
Front fork upper clamp bolt 23 2.3 16.5
Front fork lower clamp bolt 30 3.0 21.5
Front fork cap bolt
* 25 * 2.5 * 18.0
Front fork damper rod bolt
* 28 * 2.8 * 20.0
Front axle nut Normal nut with cotter pin 44 4.4 32.0
Self-lock nut 49 4.9 35.5
Front axle pinch bolt 23 2.3 16.5
Handlebar set bolt 23 2.3 16.5
Handlebar holder set nut 60 6.0 43.5
Front brake master cylinder mounting bolt 10 1.0 7.0
Front brake caliper mounting bolt 43 4.3 31.0
Front footrest bolt 23 2.3 16.5
Brake hose union bolt 23 2.3 16.5
Air bleeder valve 8 0.8 6.0
Front and rear disc bolt 23 2.3 16.5
Swingarm pivot nut 72 7.2 52.0
Rear shock absorber upper and lower mounting nut 60 6.0 43.5
Rear cusion lever rod mounting nut 85 8.5 61.5
Rear cusion lever mounting nut (Front & Center) 85 8.5 61.5
Rear brake caliper mounting bolt 26 2.6 19.0
Rear brake caliper housing bolt 33 3.3 24.0
Rear brake master cylinder rod lock nut 18 1.8 13.0
Rear brake pedal bolt 10 1.0 7.0
Torque link nut (Front & Rear) 35 3.5 25.5
Rear brake master cylinder mounting bolt 10 1.0 7.0
Rear axle nut Normal nut with cotter pin 65 6.5 47.0
Self-lock nut 78 7.8 56.5
