19-16 GS500K3 (’03-MODEL)
• Tighten the union bolt.
(Brake hose routing: ' 7-16)
& Brake hose union bolt: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
$
* The seal washers should be replaced with the new
ones to prevent fluid leakage.
* Bleed air from the system after reassembling the
master cylinder. ('2-16)

Suzuki GS500E Specifications

General

Displacement	487 cc
Bore x Stroke	74.0 mm x 56.6 mm
Compression Ratio	9.0:1
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm, coil spring, oil damped
Rear Brakes	Drum
Front Tire	110/70-17
Rear Tire	130/70-17
Engine Type	Air-cooled, 4-stroke, DOHC, parallel twin
Fuel System	Carburetor
Front Brakes	Disc brake
Fuel Capacity	17 liters
Seat Height	790 mm
Max Torque	40 Nm (29.5 lb-ft) @ 7, 500 rpm
Length	2080 mm
Wheelbase	1405 mm
