REAR SUSPENSION 17-3
REAR SHOCK ABSORBER
REMOVAL
• Place a block under chassis tube.
• Remove the seat. (5-3)
• Loosen the air cleaner clamp screw.
• Remove the right frame cover. (5-2)
• Remove the silencer and rear frame assembly.
• Remove the rear shock absorber upper mounting bolt and
nut.
(For E-19, 000)(For E-19, 000)

Suzuki RM125 Specifications

General

Ignition	CDI
Front Tire	80/100-21
Rear Tire	100/90-19
Displacement	124 cc
Front Brake	Single disc
Rear Brake	Single disc
Overall Width	830 mm
Seat Height	950 mm
Engine Type	2-stroke, single-cylinder
