CLUTCH 7-3
CLUTCH PLATE
REMOVAL
• Drain transmission oil. (2-9)
• Remove the rear brake pedal. (5-5)
• Remove the clutch cover 1.
• Loosen the bolts diagonally and remove them.
• Remove the clutch springs.
• Remove the pressure plate 2.
• Remove the bearing 3, push piece 4 and push rod 5.
• Remove the drive plates and driven plates.

Suzuki RM125 Specifications

General

Ignition	CDI
Front Tire	80/100-21
Rear Tire	100/90-19
Displacement	124 cc
Front Brake	Single disc
Rear Brake	Single disc
Overall Width	830 mm
Seat Height	950 mm
Engine Type	2-stroke, single-cylinder
