Suzuki VZR1800 Service Manual

30 VZR1800/ZL0 (’10-MODEL)
• Disconnect the front turn signal light couplers 0.
• Remove the front turn signal lights B by removing the
mounting screws A.
• Remove the front turn signal light cover bolt C.
• Remove the front turn signal cover E by removing the
cover bolts D.
• Disconnect the throttle cables F and clutch cable G.
• Remove the headlight cover brace bolts H and brake hose
joint mounting bolt I.
• Disconnect the fixed clamp and right handlebar switch coupler
J.
• Remove the headlight cover brace K along with headlight
housing bracket cover L.
• Remove the headlight housing bracket cover L from
the headlight cover brace K.
INSTALLATION
Installation is in the reverse order of removal.
Pay attention to the following point:
• Route the cables, hoses and wire harnesses properly.
(Page 38, 39, 40, 47)

Suzuki VZR1800 Specifications

General

Engine Type	4-stroke, 2-cylinder, liquid-cooled, DOHC, 54-degree V-twin
Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc, twin
Rear Brakes	Disc
Front Tire	130/70R18M/C 63H, tubeless
Ground Clearance	140mm (5.5 inches)
Seat Height	705 mm
Curb Weight	347 kg
Overall Height	1185 mm
