Synesso MVP Hydra User Manual


13
MVPHYDRAPACKAGEREQUIREMENTS&INSTALLATION 
MVP Hydra Installaon Requirements:
Electrical:
TheHydrapackagehasaslightlygreaterampdrawthanthesinglepumpmachines;pleasenotethemax
ampdrawsandplanyourelectricalinstallaonaccordingly.Seetableonpage12.
Eachpumpmotorhasadisnctcolorassociaon,whichisindicatedthroughoutthemachinebycolored
wiresandzipes.Thecolorsareasfollows:
  Group1:Grey
  Group2:Purple
  Group3:Brown
  Waterinletforthesteamtank:Pink
Whereverthesecolorsareseen,itiscricalforpropermachinefunconthattheyarematchedupcorrect‐
ly(greytogrey,etc.)forbothelectricalandplumbingsystems.
Plumbing:
Hydrapackagesrequireoneincomingwatersourcelikesinglepumpmachines.The
waterpassesthrougha
manifold(commonlypartofthelinepressureregulator)andisdistributedtoeachpump.Onceagain,fol‐
lowthecolorcodingforproperinstallaonofthehosesfromtheoutputofeachpumptothemachine.

Pressure Regulator Plumbing & Bypass Box Wiring:
Pumpcordinstallaon:Insertthecolorcodedpumpcableintotheopeningofthematchingbypassboxand
aachthewirestotheterminalasshowninthepictureabove:greenwiresstackedonthegroundbolt,white
towhite/red,blacktoblack/blue,connectthebulletconnectors.
Pressureregulator:Usedtoachievethestage1lowpressurepre‐infusion.Itissetandtestedat50psiinthe
Synesso™factory.Thispressuresengcanbeloweredifdesired,but50psiisthemaximumoutputpressure.
Toadjustthepressureregulator,firstloosenthenutonthethreadedpost,
thenturnthepostcounter‐
clockwisetodecreasepressure.
PressureRegulator
BypassBox
Pink
