TA2922 Universal Line Interface Service Manual 19
© Tait Electronics Limited March 2010
3 Installation
Note If using the universal line interface board link options on the top side of
the board, these must be set before the board is installed in the radio as
the top side of the universal line interface board is not accessible once the
board is screwed to the radio lid.
3.1 Parts Required
The following table describes the parts required to install a universal line interface
board in a radio. The parts marked with an asterisk (
*
) are not shown and are used
to connect to the radio’s external options connector.
3.2 Installation Procedure
1. Disassemble the radio in order to gain access to the options cavity.
For detailed disassembly instructions, refer to the TM8000 Service Manual.
The circled numbers in the following instructions refer to items in the diagram.
2. Remove the top cover and lid
b
from the radio to access the options
cavity.
3. Remove the external options connector bung
c
, if it is fitted.
4. On the inside of the radio lid place the foam seal
d
over the external options
connector cavity
e
.
5. With the top side of the universal line interface board
f
facing the radio lid,
guide the external options connector
g
into the external options connector
cavity.
Quantity Internal Part Number Description Reference
1 362-01111-00 foam seal
d
1 362-01108-02 cover seal
1!
2 347-00011-00 4-40x3/16 screws
1@
2 354-01043-00 screw-lock fasteners
h
6 349-02062-00 M3x8 screws
j
*
1 240-00034-00 D-range plug —
*
1 240-06010-29 D-range hood —
