TA2922 Universal Line Interface Service Manual 49
© Tait Electronics Limited March 2010
7 PCB information
The following information applies to the universal line interface board with the
PCB IPN 228-29221-00. The component values in the circuit diagram are
indicative only. Refer to the parts lists for actual values used.
7.1 Parts List XA2922-0x-PBA revision 001
The following part list contains the majority of the parts used on the 228-29221-
00 PCB. Some additional parts are fitted, as defined in “Variant parts” on page 53.
Ref IPN Description PCB Schem
C1 018-16100-10 CAP 100n 50V 10% 0603 X7R E10 1H5
C2 018-16100-10 CAP 100n 50V 10% 0603 X7R G7 1J5
C3 018-16100-10 CAP 100n 50V 10% 0603 X7R G7 1J6
C4 018-16100-10 CAP 100n 50V 10% 0603 X7R E9 1H7
C5 018-16100-10 CAP 100n 50V 10% 0603 X7R F9 1J8
C6 018-16100-10 CAP 100n 50V 10% 0603 X7R D9 1H9
C7 015-27100-08 CAPCer 1uF 16V 10% 0805 X7R D10 1B11
C8 018-16100-10 CAP 100n 50V 10% 0603 X7R C10 1F7
C9 018-16100-10 CAP 100n 50V 10% 0603 X7R D10 1H5
C10 018-16100-10 CAP 100n 50V 10% 0603 X7R B10 1J4
C11 018-16100-10 CAP 100n 50V 10% 0603 X7R E10 1H4
C12 018-16100-10 CAP 100n 50V 10% 0603 X7R B10 1J4
C13 018-16100-10 CAP 100n 50V 10% 0603 X7R C6 1E4
C14 018-16100-10 CAP 100n 50V 10% 0603 X7R C8 1E3
C15 018-16100-10 CAP 100n 50V 10% 0603 X7R D8 1F4
C16 018-16100-10 CAP 100n 50V 10% 0603 X7R A7 1K11
C17 018-16100-10 CAP 100n 50V 10% 0603 X7R F2 1C6
C18 018-16100-10 CAP 100n 50V 10% 0603 X7R F2 1B6
C19 018-16100-10 CAP 100n 50V 10% 0603 X7R F2 1C7
C20 018-16100-10 CAP 100n 50V 10% 0603 X7R G2 1C8
C21 018-16100-10 CAP 100n 50V 10% 0603 X7R F2 1C8
C22 015-27100-08 CAPCer 1uF 16V 10% 0805 X7R C10 1B10
C23 018-16100-10 CAP 100n 50V 10% 0603 X7R B6 1K9
C24 016-08100-03 CAP eltro 10uF 35V 105° 2000h F8 1J7
C25 016-08100-03 CAP eltro 10uF 35V 105° 2000h E9 1J7
C26 015-27100-08 CAPCer 1uF 16V 10% 0805 X7R B10 1F5
C27 016-08100-03 CAP eltro 10uF 35V 105° 2000h B6 1K8
C28 018-13100-00 CAP 100p 50V NPO ±5% 0603 F9 1J7
C29 018-13100-00 CAP 100p 50V NPO ±5% 0603 D10 1H4
C30 018-16100-10 CAP 100n 50V 10% 0603 X7R G8 1J6
C31 016-08100-03 CAP eltro 10uF 35V 105° 2000h F9 1H10
C32 018-13100-00 CAP 100p 50V NPO ±5% 0603 D9 1G8
C33 018-13100-00 CAP 100p 50V NPO ±5% 0603 E8 1C9
C34 018-13470-00 CAP 470p 50V ±10% 0603 X7R E6 1J8
C35 018-15100-00 CAP 10n 50V ±10% 0603 X7R G5 1J10
C36 018-15100-00 CAP 10n 50V ±10% 0603 X7R F6 1G10
C37 018-14100-00 CAP 1n 50V ±10% 0603 X7R D1 1J13
C38 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1J13
C39 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1J13
