Blind control
74
Parameters
Blind settings
Slat time
Slat idle time
Slats horizonzal at
Direction change
delay
Delay
Time taken by the slats to move from horizontal to closed
Idle time in a change of direction; option of correcting to
compensate for wear of blind after a long period of use
Value for horizontal slat position for the input signal "Set
horizontally"
Specifies a delay when changing direction
Specifies a delay for auto mode commands
Manual mode
Long click time
Double click time
Manual height setting
Manual inclination setting
If the long click time is exceeded for the input signals Open blind
or Close blind, the blind will be opened or closed fully (enter value
= 0 to deactivate).
If two pulses are received within the double click time on the input
variables Open blind or Close blind, the blind will be opened or
closed fully (enter value = 0 to deactivate).
Required height for manual mode
Required inclination for manual mode
Closing conditions
if enable = off
if enable auto mode = off
if safety shutdown
Action of the function if Enable = OFF.
Action of the function if Enable auto mode = OFF.
Action of the function when the safety shutdown is active.
Available for selection: Close, Open, Unchanged
Trigger auto mode
Open blind
Close blind
Fully open blind
Fully close blind
Buttons for switching to auto mode, manual mode and horizontal
setting of the blind slats
➢ Direction change delay: Applies in both manual and automatic mode. Some blind
manufacturers specify a delay when changing directions, in order to reduce wear on the
drive.
➢ Delay: Applies only in automatic mode. If this delay is set differently in different blind
functions, the blinds will not be moved simultaneously by the Shading function.
➢ Manual inclination and height settings: If users select one of these two parameters in
automatic or manual mode, the selected blind position will be issued as the set position,
even if users have not changed the value. In any case the function will then be in manual
mode (Auto mode = Off).
