TECO JSDAP-75A3 User Manual

2-9
2-1-5 TB Terminal
Name
Terminal
Sign
Detail
r
s
200V
 Connecting to external AC Power.
 Single Phase 200~230VAC +10 ~ -15% 50/60Hz ±5%
24V
Control circuit power
input terminal
0V
400V
 Connecting to external DC Power.
 Single Phase 24VDC ±10%.
R
S
Main circuit power input
terminal
T
200V
 Connecting to external AC Power.
 Single / 3 Phase 200~230VAC +10 ~ -15% 50/60Hz ±5%
400V
 Connecting to external AC Power.
 Three Phase 380~480VAC ±10% 50/60Hz ±5%
External regeneration
resistance terminal
P
Regeneration terminal
common point
PC
Internal regeneration
resistance terminal
P1
Please refer to Cn012 to see resistance value, when using external regeneration
resistance. After installing regeneration resistance, set the resistance power in
Cn012.
*If no using external regeneration resistance, PC-P1 need be close, P
doesn’t be connected.
*When using external regeneration, equip regeneration resistance
between PC-P, do not connect P1 terminal.
U
Motor terminal wire is red
V
Motor terminal wire is white
Motor-power output
terminal
W
Motor terminal wire is black
Motor-case grounding
terminal
FG
Motor terminal wire is green or yellow-green.
TB Terminal Tightening Torque
Max. Tightening Torque (kgf-cm / in-lbs)
Servo Pack Model
Control circuit terminal(r , s) Main circuit terminal(R, S, T)
JSDAP-10A 10 / 8.7
JSDAP-15A 10 / 8.7
JSDAP-20A 10 / 8.7
JSDAP-30A 10 / 8.7
JSDAP-50A3 16 / 13.9
JSDAP-75A3 16 / 13.9
JSDAP-100A3 16 / 13.9
JSDAP-150A3 18 / 15.6 30 / 26
JSDAP-200A3 15 / 13 30 / 26
JSDAP-300A3 15 / 13 30 / 26
JSDAP-25B 16 / 13.9
JSDAP-35B 16 / 13.9
JSDAP-50B 16 / 13.9
JSDAP-75B 18 / 15.6 30 / 26
JSDAP-100B 18 / 15.6 30 / 26
