TECO JSDAP-75A3 User Manual

2-24
2-2-2 Encoder Connector (CN2) Terminal Layout
(1) Diagram of CN2 Terminal:
(a) Diagram of Fewer Wiring Type Encoder:
(b) Diagram of 15 bits / 17 bits Encoder:
1 Vcc
Power Supply
Output
3 GND Ground
5 --
7
9
2
4
6
8
10
11 VB+ Battery(+)
13 SD
Serial Data
output(+)
15
17
19
12 VB- Battery(-)
14 /SD
Serial Data
output(-)
16
18
20
Pin
No.
Terminal
Layout
Function
P.S.: Do not wire to the terminal, which is un-operated.
